Styrok Prefabricated Wall Panels

An alternative to Indiana limestone, ACM panels and precast panels.

Unlike traditional exterior stone cladding (which weighs about 40-50 lbs per square foot), our heaviest panels weigh only about 3 lbs per sq foot, so no mechanical fastening or structural support is required. This makes for a quicker and more cost-effective installation process.



Another key advantage of our prefab concrete panels is that they're low-maintenance. They're made of glass fibre reinforced concrete and sealed with a nano-penetrating sealer, so they're non-porous and highly moisture-resistant. This means they won't absorb dirt, dust or water the way that natural stone or precast does


Smooth, Engineered Limestone Panels

Finish: Like honed, smooth-cut limestone



2' x 4' | 2' x 6' | 2' x 8' *

Smooth, Engineered Limestone Panels

Finish: Like honed, smooth-cut limestone



2' x 4' | 2' x 6' | 2' x 8' *


Prefinished, Extruded Panels



Finish: like precast

From 4-36" wide x 8' long *

Lime-ROK                                T-ROK                                  Stycast

* All panels can be cut to a smaller size using a diamond blade.

How it's Installed

Styrok lightweight wall panels are easy to install. For existing construction, they can be installed directly over existing masonry (provided the substrate is in good condition).  For new construction (or where the substrate is not in good condition), they are installed over a EIFS wall assembly, replacing the finish coat. In both cases, panels are adhered to the wall using an exterior grade polymerized adhesive.

Just like with limestone or precast panels, pattern layout and joint location are important aesthetic elements that must be considered. Styrok panels are installed in a similar manner to limestone cladding:

1

2

3

Cut to size using a diamond blade

Install in a desired pattern

Grout the joints
